30-days-30-projects

RGBordle

A wordle-esque game where players try to guess RGB colors in 6 tries or less.

Try it out here!

Tech Stack

Install and Run

  1. Download / navigate to the /9-rgbordle directory.
  2. Run npm i to install the necessary dependencies.
  3. Run npm start.

A new browser window should open to http://localhost:3000, where you should be able to start using the app.

Implementation

Most of the functionality is similar to any other wordle clone: an array of guesses are stored in state, and as the player makes guesses each tile is checked for accuracy and colored accordingly. The game ends when the user is either out of guesses or has a completely correct guess.

While I won’t go through every single component, I’ll point out some of the more interesting snippets.

Generating the random color

In order for the game to work, we need to generate a random color that the player should try to guess. In this case, the color is just an Array(3) of integers from 0 to 250 that represent the r, g, and b components of an RGB color:

const getRandomColor = () => {
    const r = Math.floor(Math.random() * 26) * 10;
    const g = Math.floor(Math.random() * 26) * 10;
    const b = Math.floor(Math.random() * 26) * 10;
    return [r, g, b];
};

The reason we max out at 250 rather than the actual maximum value 255 is because each of the 3 values are multiples of 10. That way, guessing the exact combination of r, g, and b values is actually doable in 6 guesses.

We have a Color component, which displays the color box to the left of the tiles. This component is in charge of generating the random color, and the way we display the color is somewhat interesting.

We don’t want to just generate the color and set it as a backgroundColor, because it would be too easy for players to cheat by inspecting the element’s styles. Instead, we do the following once the component has mounted:

  1. Generate the random [r, g, b] array.
  2. Create an svg string, setting its fill color to our randomly generated color.
  3. Use the DOMParser.parseFromString method to parse the string as an XMLDocument.
  4. Serialize the XMLDocument using the XMLSerializer.serializeToString.
  5. Use window.btoa to Base64-encode our serialized string.

Player’s aren’t able to inspect elements and check the color without going through the trouble of decoding the image’s src. Our useEffect hook looks like this:

const [src, setSrc] = useState(null);

useEffect(() => {
    const randomColor = getRandomColor();
    // Create an SVG string with a the random color
    const svg = `<svg viewBox="0 0 80 80" xmlns="http://www.w3.org/2000/svg">
        <rect x="0" y="0" width="80" height="80" fill="rgb(${randomColor.join(',')})" />
    </svg>`;
    // Convert the SVG string to XML, then encode to base64 so that the color is not
    // obtainable by inspecting elements
    const xmlDoc = new DOMParser().parseFromString(svg, 'application/xml');
    const serializedXml = new XMLSerializer().serializeToString(xmlDoc);
    const encodedXml = window.btoa(serializedXml);
    // Update the src in state so we can use it for our <img> element
    // Send the random color to the game component
    setColor(randomColor);
}, []);

and we render like so:

return (
    <div className='Color'>
        <img className='Color__img' src={src} />
    </div>
);

Handling guesses

Guesses are submitted through a form using input elements of type number with min and max attributes set, so we don’t have to check for validity other than ensuring all inputs have a value.

We have 3 different cases for each guessed value:

  1. The tile is green if the guessed value is equal to the corresponding answer value.
  2. The tile is yellow if the guessed value is within 25 of the corresponding answer value.
  3. The tile is grey otherwise.

We send the three r, g, b values to a makeGuess function in our Game component. To check the guess and assign a color to each tile, we create an array [r, g, b] and loop through it, checking the conditions listed above:

Additionally, we keep track of how many correct values are in the current guess. Once we’ve determined the color of each tile, we can add the guess to our guess array, which will be rendered by the Guesses component.

Before setting our updated guess array in state, we check for any game over conditions, namely:

With 3 correct guesses we’ve guessed all 3 of the values, and if we’ve made 6 guesses then we’ve run out of guesses. If the game is over, we handle it accordingly in an endGame function.

const makeGuess = (r, g, b) => {
    if (guessNumber === 6) return;
    // The array in state that stores all guesses
    const guessed = guesses;
    // A counter for the number of correct values this guess
    let numCorrect = 0;
    // Loop through each guessed value
    const guess = [r, g, b].map((value, i) => {
        // Tile color is grey by default
        let tile = 'grey';
        // If the guess is correct, the tile is green
        if (value == color[i]) {
            tile = 'green';
            // Increment our correct value counter
            numCorrect++;
        // If the guess is within 25, the tile is yellow
        } else if (Math.abs(value - color[i]) <= 25){
            tile = 'yellow';
        }
        // Return the guess and the tile color
         return { value, color: tile };
    });
    // Update our guess array
    guessed[guessNumber] = guess;
    // Check win conditions
    if (numCorrect === 3 || guessNumber + 1 === 6) {
        endGame(numCorrect === 3, guessNumber);
    }
    // Set our state values
    setGuesses(guessed);
    setCorrect(numCorrect);
    setGuessNumber(guessNumber + 1);
};

Storing data

Some of the application data persists between sessions using localStorage. We store two values: theme, to keep track of whether the user prefers dark or light, and stats, to keep track of the users stats.

Once the Game component mounts, we grab the stats from localStorage and store them in state so that they can be sent to the Stats modal. On game end, we update the stats object like so:

const endGame = (won, totalGuesses) => {
    // Increment total games played
    const games = stats.games + 1;
    // Increment wins if the game was won
    const wins = stats.wins + !!won;
    // Increment the streak if the game was won, otherwise set to 0
    const streak = won ? stats.streak + 1 : 0;
    // Update the max streak if necessary
    const maxStreak = Math.max(streak, stats.maxStreak);
    // Update the guess distribution if necessary
    const guessDistribution = stats.guessDistribution;
    if (won) guessDistribution[totalGuesses]++;
    // Update the stats in state
    setStats({ games, wins, streak, maxStreak, guessDistribution });
};

// Listen for changes to the stats in state and update localStorage
useEffect(() => {
    if (!stats) return;
    localStorage.setItem('rgb-stats', JSON.stringify(stats));
}, [stats]);
